Description
The Ultrasonic energy is produced by converting electrical energy in to Mechanical Vibrations by using generator and piezo Electric Transducers. Due to Mechanical Vibrations in cleaning liquid this Phenomenon is called cavitation. In a very short time it removes all dirt & foreign bodies from components which are immersed in the cleaning liquid.
| · Continuous Self Tuning Circuitry For Any change In Workload, Liquid Level And Bath Temp |
- Uniform Cavitations Through Out The Tank
- Separate Oscillator Eliminates Damage To Generator In Case of Failure Of Transducers
- Using 40 Khz Frequency For Effective Cleaning With Low Noise
- Designed For Complete Cleaning Of Small and Large Components Without Dismantling
| Tank Volume (Litres) | 1.8L | 2.5 L | 4L | 6 L | 9 L | 12 L | ||
| Ultrasonic Wattage | 50 W | 50 W | 100 W | 150 W | 200 W | 200 W | ||
| Ultrasonic Frequency | 40±3 KHz | |||||||
| Tank Dimension ( Taper) LxWxH (mm) | 150x
137x 100 |
150x
137x 150 |
235x
135x 150 |
300x
153x 150 |
300x
240x 150 |
300x
240x 150 |
||
| Outer Dimension LxWxH(mm) | 175x
165x 200 |
175x
165x 250 |
265x
165x 290 |
325x
175x 290 |
325x
265x 290 |
325x
265 x340 |
||
| Heating | Ambient to 80°C Digitally Controlled (Dual Display) | |||||||
| Digital Timer | 5 to 60 minutes | |||||||
| Tank Drain | N/A | Ball Valve | ||||||
| Inner Tank Material | Stainless Steel | |||||||
| Outer Housing Material | Stainless Steel | |||||||
| Power Supply | 220Volt, Ac 50 Hz, Single Phase | |||||||
